Introduction: Pre-assembled for quick and easy installation.
Material: Carbon Steel,Stainless Steel A2,Stainless Steel A4
Surface Treatment: BZP,YZP,HDG
Grade：Grade 4.8,Grade 6.8,Grade 8.8
Applications: Thin sections of Concrete and Solid Masonry.
|
Code |
Size |
Thread |
Drill Diameter |
Length |
|
ES-08045 |
M6 x 8 x 45 |
M6-P1.0 |
8mm |
45mm |
|
ES-08060 |
M6 x 8 x 60 |
M6-P1.0 |
8mm |
60mm |
|
ES-10060 |
M8 x 10 x 60 |
M8-P1.25 |
10mm |
60mm |
|
ES-10080 |
M8 x 10 x 80 |
M8-P1.25 |
10mm |
80mm |
|
ES-12070 |
M10 x 12 x 70 |
M10-P1.5 |
12mm |
70mm |
|
ES-12100 |
M10 x 12 x 100 |
M10-P1.5 |
12mm |
100mm |
|
ES-16080 |
M12 x 16 x80 |
M12-P1.75 |
16mm |
80mm |
|
ES-16100 |
M12 x 16 x 100 |
M12-P1.75 |
16mm |
100mm |
|
ES-16110 |
M12 x 16 x 110 |
M12-P1.75 |
16mm |
110mm |
|
ES-20080 |
M16 x 20 x 80 |
M16-P2.0 |
20mm |
80mm |
|
ES-20110 |
M16 x 20 x 110 |
M16-P2.0 |
20mm |
110mm |
(Only some sizes are listed,other sizes can also be produced.)
